OEM Semi Automatic Crimping Machine

Product Categories

Chenxin Automation Equipment(Guangzhou) Co., Ltd.

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: OEM Semi Automatic Crimping Machine
Brand: CHENXIN
Price: 1 USD

Brand Name : CHENXIN

Model Number : CX-GX02

Certification : ISO9001

Place of Origin : CHINA

MOQ : 5 sets

Price : FOB Shenzhen

Payment Terms : T/T

Supply Ability : 500 sets per month

Delivery Time : 7-10 working days

Packaging Details : wooden case/box

Stripping length : Max.17mm

Capacity : 2.5sec/wire

Applicable wire : BVR wire 0.5,0.75,1.0,1.5,2.5,4.0mm2

Applicable terminal : Insulator length ≤7.5mm,conductor length≤10mm

Crimping shape : Quadrilateral Crimp

Control mode : human-machine interface, electronic control, pneumatic control

Operation mode : Automatic trigger operation and manual operation

Contact Now

Electric Semi-Automatic Cable Terminals Crimp Machine Insulated Ferrule Wire Terminal Strip Crimping Machine

Technical Parameter

Model of machine	CX-GX02
Stripping length	Max.17mm
Capacity	2.5sec/wire
Applicable wire	BVR wire 0.5,0.75,1.0,1.5,2.5,4.0mm2
Applicable terminal	Insulator length ≤7.5mm,conductor length≤10mm
Crimping shape	Quadrilateral Crimp
Control mode	human-machine interface, electronic control, pneumatic control
Operation mode	Automatic trigger operation and manual operation
Air pressure	0.6-0.8mpa
Working temperature	10-25℃
Power source	AC220V/110V/50/60HZ
Weight	40KG
Dimension	W350mm×L450mm×H400mm

OEM Semi Automatic Crimping Machine

Product Tags:

4.0mm2 Semi Automatic Crimping Machine
